Product Details
Place of Origin: China
Brand Name: DST
Certification: SGS
Model Number: DSH
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: Based on specification
Packaging Details: wooden case
Delivery Time: around 4 months
Payment Terms: T/T
Supply Ability: 4 sets in four months
Substrate: |
Wet-process Sepatate Film |
Substrate Width: |
3200mm－4200mm |
Substrate Thickness: |
Inlet15～45μm ,outlet 10～30μm |
Speed: |
10-75m/min |
Extraction Liquid: |
Dichloromethane |
Roll Surface Length: |
4500mm |
Electricity: |
3 Phase * 200 Volt *60Hz |
Color: |
OEM |
Warranty: |
12 Months |
Payment: |
TT |
Substrate: |
Wet-process Sepatate Film |
Substrate Width: |
3200mm－4200mm |
Substrate Thickness: |
Inlet15～45μm ,outlet 10～30μm |
Speed: |
10-75m/min |
Extraction Liquid: |
Dichloromethane |
Roll Surface Length: |
4500mm |
Electricity: |
3 Phase * 200 Volt *60Hz |
Color: |
OEM |
Warranty: |
12 Months |
Payment: |
TT |
DSE-Serie Extraction Winder Film Width 3200mm－4200mm With High Speed 10-75m/Min
A floating roll is set at the front end of the film inlet groove to match the speed of the exit of the front stretching system. A guide roll and a pressure roll are arranged at the entrance of the film inlet groove. When the whole line is shut down for maintenance, the pressure roll can press the diaphragm to facilitate the next film threading. In the normal production process, the pressure roll can be used or not according to the actual production situation.
The pure water seal mechanism is set in the film inlet tank, and dichloromethane is slightly soluble in water. In the production process, the water seal separates the front atmosphere from the cleaning tank, which can effectively reduce the volatilization of dichloromethane. An adjusting roll is set at the outlet of the film inlet end. The roll can be adjusted horizontally. If the diaphragm is wrinkled, it can be adjusted quickly through the adjusting roll.
Technical Data
| Substrate | wet-process sepatate film |
| Substrate Width | 3200mm－4200mm |
| Substrate thickness | inlet15～45μm ,outlet 10～30μm |
| Electricity | 3 phase * 200 volt *60Hz |
| Speed | 10-75m/min |
| Extraction liquid | dichloromethane |
| Color | OEM |
| Warranty | 12months |
| Payment term | TT |
| Power supply | AC380V, 50Hz,three phase current |
Features
Competitive Advantages
1. We offer high quality products at competitive price;
2. customs clearance is guaranteed;
3. Good after-sale service;
4. Flexible payment terms;
5. With excellent products and efficient services, we are well known both at home and abroad.
Packaging & Delivery
1. Prompt delivery;
2. Professional logistic agent;
3. Well-trained and disciplined packing team;
4. After-sale service: Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
Our Factory
Dongheng(dswintec.com) located in HeFei city and SuZhou city, Dongsheng M&E Tech Co.,Ltd. is a well-known manufacturer of functional-film equipments. The company specializes in manufacturing vacuum coating machines, splitting machines, rewinding machines, bidirectional film-pulling machines, and other related equipments, for fields of electronic films, lithium battery separators, optical films, packing films, cooper/aluminum foil and others.
Dongsheng is also equipped with well-qualified R&D personnel,and experienced mechanical and electrical application engineers. Oriented to customers requirements and satisfaction, Dongsheng is dedicated to provide integrated solutions for designing & manufacturing,upgrading & reconstruction for used equipments, process designing, equipment installation, technical consultation,and personnel training, from single devices to whole production lines.
With excellent products and efficient services, DONGSHENG is obtaining more and more satisfaction and support from users at home and abroad.
FAQ
Q: Is Dongsheng a factory or trading company?
A: Dongsheng is a factory.
Q:Where is your factory located? Can I visit it before I place an order?
A:Our factory is located in Hefei, Anhui,China; Welcome to visit our factory.
Q: How about the warranty and after-sale service?
A: We provide 12 months warranty and lifetime technic suport for all machinery.
The response is available within 12 hours while the solution for the troubleshooting is provided within 48 hours.
Q. Machine installation
A. We could assign the technician to the place for the on-site installation if requested by the purchase
