Product Details
Place of Origin: China
Brand Name: DST
Certification: SGS
Model Number: MCA
Payment & Shipping Terms
Minimum Order Quantity: 1set
Price: Based on Specification
Packaging Details: Wooden case
Delivery Time: Rround 6 months
Payment Terms: T/T
Supply Ability: Five sets in 6 months
Substrate: |
OPP, PET Etc. |
Substrate Thickness: |
OPP 2.0μm-12μm, PET 0.8μm-12μm |
Substrate Width: |
500mm~1000mm |
Roll Diameter: |
Φ150mm, Φ75mm |
Coating Film: |
Customized |
Speed: |
Max.1200mm |
Operation Screen: |
Colorful Touch Screen |
Certification: |
ISO 9000 |
Substrate: |
OPP, PET Etc. |
Substrate Thickness: |
OPP 2.0μm-12μm, PET 0.8μm-12μm |
Substrate Width: |
500mm~1000mm |
Roll Diameter: |
Φ150mm, Φ75mm |
Coating Film: |
Customized |
Speed: |
Max.1200mm |
Operation Screen: |
Colorful Touch Screen |
Certification: |
ISO 9000 |
600mm Steel Coating Drum Vacuum Metallizing Machine Used To Produce Metalized Film For Capacitors
Product Description
The high vacuum mesh coating system described in this article is specifically designed for single-sided coatings of flexible mesh materials with metal layers. The metal layer can be pure aluminum or zinc/aluminum. Metallized materials are used in the production of dielectric thin film capacitors.
Technical Data
| Substrate | OPP, PET, etc. |
| Substrate Width | Max.1200mm |
| Substrate thickness | OPP 2.0μm-12μm, PET 0.8μm-12μm |
| Heating method | Evaporation boat |
| Speed | Max. 1200m/min |
| Coating material |
metal, plastic, impregnated paper
|
| Core diameter (inside) |
76 mm or 152 mm
|
| Coating material |
Al.only; Zn.,Al.
|
|
Roll Diameter |
Max. 600mm |
Basic Features
1. High precision winding system:
Digital wire wound electronic products can be horizontally unfolded. Two different rewind modes.
2. Spreader drum:
The metal straight spreading roller achieves uniform tension across the entire width of the coil, and achieves uniform coating and rewinding.
3. Combination evaporation system, used for:
1) Aluminum source
A thermal evaporator for resistance heating of intermetallic composite materials. Continuous aluminum wire feed system for easy observation.
2) Zinc source
Radiation heating furnace for zinc evaporation. A nozzle plate used for uniform or reinforced edge coating.
4. Advanced oil blocking system:
Advanced oil mask system used to generate non-metallic stripes in the direction of the roll paper. Multi position high-precision remote control and adjustment of the evaporation oil pipe, with digital indications on the touch screen. Radiation oil heating and oil pollution prevention design.
5. Precision process control:
Industrial Personal Computer Control System Based on Window Operation.
Packaging & Delivery
1. Prompt delivery;
2. Professional logistic agent;
3. Well-trained and disciplined packing team;
4. After-sale service: Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
Competitive Advantages
1. We offer high quality products at competitive price;
2. customs clearance is guaranteed;
3. Good after-sale service;
4. Flexible payment terms;
5. With excellent products and efficient services, we are well known both at home and abroad.
Our Factory
Our customers
FAQ
Q: Is Dongsheng a factory or trading company?
A: Dongsheng is a factory.
Q:Where is your factory located? Can I visit it before I place an order?
A: Of course, welcome to visit our factory. Our factory is located in Hefei, Anhui,China.
Q: Which countries have you exported to?
A: We have exported our products to all over the world, such as Europe, USA, Japan, Korea, India etc.
Q. Payment Terms
A. TT 30% down payment, 70% before shipment.
Q: How about the warranty and after-sale service?
A: We provide 12 months warranty and lifetime technic suport for all machinery.
The response is available within 12 hours while the solution for the troubleshooting is provided within 48 hours.
